lock-motor-late.jpg Late-model door lock motor. 8" when extended; gold mounting bracket & nuts shown are not included, but silver clip & pigtail are.

F-series & Broncos do not use the bridge bracket with 2 nuts; in trucks, the white (silver) lock motor yoke is riveted directly to the door skin.
lock-motor-late.jpg | Hits: 3497 | Posted on: 11/27/04 | View original size (112.88 KB)

Late-model door lock motor. 8" when extended; gold mounting bracket & nuts shown are not included, but silver clip & pigtail are.

F-series & Broncos do not use the bridge bracket with 2 nuts; in trucks, the white (silver) lock motor yoke is riveted directly to the door skin.
