img_5718.jpg everything back together.

Post note, the front end needed some work at this point to get all the geometry in line. The tie rod was too long by a couple of inches and as a result needed to be shortened. I switched to a regular pitman arm instead of a dropped one and that improved the drag links alignment with the track bar. The track bar is an adjustable style from superlift.
img_5718.jpg | Hits: 311 | Posted on: 10/4/16 | View original size (1.03 MB)

everything back together.

Post note, the front end needed some work at this point to get all the geometry in line. The tie rod was too long by a couple of inches and as a result needed to be shortened. I switched to a regular pitman arm instead of a dropped one and that improved the drag links alignment with the track bar. The track bar is an adjustable style from superlift.
