9509 hits | 76.63 KB | Posted: 3/11/07
E-brake specs.

2388 hits | 78.95 KB | Posted: 2/7/07
A/C & Belt Routing Label

3841 hits | 73.79 KB | Posted: 2/7/07
Emissions Label

3265 hits | 58.32 KB | Posted: 12/18/06
I cleaned up most of the debris off the road.

2671 hits | 59.07 KB | Posted: 12/18/06
There's not as much damage on this side because I was offcenter behind the truck.

2543 hits | 57.81 KB | Posted: 12/18/06
The hood & its strike are bent.

2636 hits | 71.84 KB | Posted: 12/18/06
The bumper cover is shredded, but I was able to push it back into place. The bumper itself wasn't touched.

2709 hits | 52.94 KB | Posted: 12/18/06
This blinker assy. blew off as I was driving home. No great loss, obviously.

2566 hits | 62.67 KB | Posted: 12/18/06
The header panel clipped the gold speaker wire for my RV mirror temperature sensor, and even though it went into the condenser core, it didn't rupture it. It's still getting replaced, though.

9509 hits | 76.63 KB | Posted: 3/11/07
E-brake specs.

7532 hits | 67.39 KB | Posted: 11/30/06
None of the keys I got with the car worked very well in the ignition, so I bought a new lock cylinder at the dealership & had a key cut by the numbers to match the doors. I assembled & installed the cylinder per the included instructions & it works ...

6789 hits | 75.21 KB | Posted: 11/12/06
These diagrams are for 1999, but the information is generally applicable to '95-up.

Dark Mode (no dome lights or chime for any open door) can be enabled by connecting the factory connectors C200M & C200F (light blue under the glove box) and then ...

5648 hits | 57.6 KB | Posted: 12/6/06
I used a long gasket box in the middle to support the junk '94 headliner so I could see & drive home.

4770 hits | 50.16 KB | Posted: 12/6/06
To install a headliner without damage or removing the front or rear windows, first slide the seats fully back, and recline them fully. The transmission tunnel must be exposed (NO center console forward of the seats). Tilt the steering wheel up, & c...

4639 hits | 58.28 KB | Posted: 12/18/06
This Tahoe's bumper was JUST high enough to go over mine.

4530 hits | 84.23 KB | Posted: 11/21/06
The coil barely fits wedged between the extension & the fuel rail, which gives it the most strength to hold the spark plug down in the hole. Having the hole plugged prevents debris from entering the cylinder, and provides more balance to the engine ...

4388 hits | 59.76 KB | Posted: 11/21/06
The old coil probably still works fine, but I decided to replace it anyway. Same for the spark plug, if I had regapped it, but the boot was chewed up.

4227 hits | 66.42 KB | Posted: 12/6/06
Next, rotate the headliner's LHR corner (at the bottom near the driver's door) up along the L side of the car & work the LHF corner through the R footwell and across the trans tunnel. Keep the R edge of the headliner high in the door opening.
