x1.JPG 4295 hits | 35.08 KB | Posted: 6/30/03 Im not happy with the shackle angle here. Also the pinion angle is not even close to perfect, it binds with about 4 in of upward travel. It was a shot in the dark and I missed. I redrilled new holes in the front hanger about 1" back and .25" down....
Project_X_Rr_Hgr_b.JPG 4114 hits | 34.85 KB | Posted: 6/30/03 Bolted on then welded to the frame and the body mount.
shac.JPG 3874 hits | 43.88 KB | Posted: 6/30/03 These shackles are key to the installation. They are about one inch longer that ORU's design plus the 2" square center support is beefier. I got them custom made for only $29! from Southwest 4x4 - call John Nord @ 915-365-3891. Ill mount them in t...
Project_X_Tow_Strap.JPG 3859 hits | 31.69 KB | Posted: 6/30/03 Uses for a tow strap: #1001 - Preventing vehicle from rolling down angled driveway while SASing.
Ready_for_the_Swap!.JPG 3721 hits | 33.06 KB | Posted: 6/30/03 Getting there! Ready to roll under the big dog!
Shackle_Hanger_1.JPG 3609 hits | 42.9 KB | Posted: 6/30/03 Used .25" thk square tubing for custom shackle hangers.
