2577 hits | 46.25 KB | Posted: 12/11/08
Wiper Valance

I had it painted black to put on my '83, but it doesn't fit. So it has been stored outdoors for the past ~4 years.

4630 hits | 78.43 KB | Posted: 3/25/07
It's dead, Jim.

It'll probably become a bridge over a narrow gully for 4-wheelers. The body mounts shown are now SOLD, and so are a few of the Xmbr gussets.



...or maybe it'll replace this one:

[url=http://www.supermotors.net/registry/media/1059...

4722 hits | 80.02 KB | Posted: 5/6/06
SOLD It's on the way to the welder.

Crate 18.JPG
3030 hits | 31.54 KB | Posted: 1/3/05
SOLD The dark ones were with the flash.

Crate 17.JPG
3033 hits | 31.44 KB | Posted: 1/3/05
SOLD The dark ones were with the flash.

Crate 19.JPG
3677 hits | 41.06 KB | Posted: 1/3/05
SOLDThe blurry ones were with the flash turned off.

Crate 15.JPG
3934 hits | 37.63 KB | Posted: 1/3/05
SOLD The blurry ones were with the flash turned off.

Crate 14.JPG
5145 hits | 63.44 KB | Posted: 1/3/05
SOLD Yes, that's a complete ready-to-run 5.8L engine (& a few other odd parts) in a LARGE crate (~$40 in lumber on a free pallet) on a HEAVY steel hitch-hauler.

[url=http://www.supermotors.net/registry/media/149304][img]http://www.supermotors.net/g...

8621 hits | 55.6 KB | Posted: 1/1/05
DPFEGR on '96 5.8L

Right kick modules.JPG
16976 hits | 80.83 KB | Posted: 7/11/03
ERROR ! ! ! ! ! ! ! ! ! !

The module I MISlabelled as "Airbag" is actually the Wiper Control Module (WCM). The Airbag Diagnostic Module (ADM) is light blue, wrapped in black foam, above the gas pedal.

96 Side.JPG
9302 hits | 109.5 KB | Posted: 7/7/03
SOLD body tub, title, & camper shell

9014 hits | 59.54 KB | Posted: 7/11/03

8621 hits | 55.6 KB | Posted: 1/1/05
DPFEGR on '96 5.8L

Timing Pointer.JPG
8091 hits | 102.12 KB | Posted: 7/11/03
Timing Pointer & Misfire Sensor used only on '96 OBD-II smallblock engines. The lower L pulley is a factory idler where the unneeded air pump used to go. The '96 cats are Oxygen-storing, so they don't need 2ndry air.

[url=http://www.supermotors.ne...

Keyless entry module.JPG
7016 hits | 70.49 KB | Posted: 7/11/03
SOLD RKE module in '94-96 F150s & Broncos is above the gas pedal behind the knee bolster pocket. The large number on the label is the master code for the keypad (if one is connected, but those trucks didn't get a keypad from the factory).

[url=http...

Dash Rear L.JPG
6851 hits | 97.37 KB | Posted: 7/11/03
The big flat plate attached to the back of the dash is the stock '94-96 Premium Sound amplifier mount. It slides straight up into place, and is retained by a simple plastic catch at the bottom, so it's easy to drop out of the dash without any other ...

Engine T.JPG
6660 hits | 96.71 KB | Posted: 7/11/03
SOLD

Dash Rear R.JPG
6464 hits | 101.98 KB | Posted: 7/11/03
After lowering the column, removing the big Aluminum casting, unbolting the 2 large connectors under the brake booster & releasing them from the firewall, the 3 connectors in the R kick, & the green ground screw, there are four 7mm (T15) screws along...
