997 hits | 79.76 KB | Posted: 1/5/09
the real wheeling photos are at
http://www.flickr.com/photos/nallabor

but there aren't that many

808 hits | 92.65 KB | Posted: 1/5/09

866 hits | 69.54 KB | Posted: 1/5/09

836 hits | 100.04 KB | Posted: 1/5/09

766 hits | 41.05 KB | Posted: 1/3/09

822 hits | 65.37 KB | Posted: 1/3/09
Crappy picture, poser shots in a couple of days

913 hits | 87.84 KB | Posted: 7/4/08
Needs driveshafts, brakelines, and wheels/tires mounted. Mmmm... 4-corner discs.

725 hits | 109.45 KB | Posted: 7/4/08
In order to put the top surface of the high-steer arm at a close angle to the TRE's face, I milled it down some.

I think I made the steering arm too long. I wanted to provide as much leverage as possible against the large tires, but failed to think ...

908 hits | 105.61 KB | Posted: 7/4/08
Decent draglink angle... only bad thing is the knuckles are tilted inwards in order to get camber for turning, so the high-steer arm adds more angle for the TRE. It is even worse when the passenger side suspension compresses, bad enough so that the T...

Rear Only Lifted 003.jpg
2885 hits | 39.76 KB | Posted: 3/22/06
Haha, I have about a half an inch of clearance. Im liking it how it is, Im leaving it.

ZF Insides.jpg
2781 hits | 78.03 KB | Posted: 5/6/06
ZF S5-42 insides.

Tires 01.jpg
2708 hits | 81.33 KB | Posted: 4/29/06
46" Michelin XML's.
46x16.5R20
Hard Compound, not many biting edges... poor man's 46's.

flooded 1.jpg
2481 hits | 34.03 KB | Posted: 8/8/05
Still wont float...
I had no 4wd, thanks to the trusty auto hubs. Got stuck in hte middle of a river. Sole reason I switched to manual hubs. Truck ran the whole time... water level 1" below air intake.

Exhaust Under.jpg
2368 hits | 71.93 KB | Posted: 11/6/05
Underneath the truck. 3" ATS downpipe upgrade, then straight pipe, no muffler to a 60 degree bend out in front of the rear passenger tire. Sounds badass....

Edit: I got rid of the exhaust, am running downpipe.

Rob Transmission 02.jpg
2358 hits | 85.57 KB | Posted: 7/14/06
ZF S5-42 main housing. I thought it was going to be heavier.

1876 hits | 73.63 KB | Posted: 8/12/07
Pre '94 F700 front rotors, '99-'04 F350 calipers & a little fabrication. The calipers had to be machined out 3/8" in order to fit over the F700 rotors. For this reason, I recommend using F550 calipers as the machining isn't hardly worth the efforts. ...

Flooded 2.jpg
1583 hits | 33.06 KB | Posted: 8/8/05
Flooded interior. It was January, about 40 degrees out. Cameron (aka Dosdovi on here and FSB) threw the tractor keys across the river only to have the wind pick up and land them right in the river...(at least) 30 minutes later we were well on our wa...

205 Mount 003.jpg
1425 hits | 71.36 KB | Posted: 7/28/06
I'm not going to use this, it will hang way too low, and snag on every rock/obstacle.

The new one is out of DOM tubing that all joins up to two pieces of 2"x2" 0.25 wall tubing that each bolts to the frame via 3 recessed bolts per side. Pics later....
