swingstrkbolt.jpg Type 3 Bronco Swingaway Spare Carrier Strike Bolt & Sleeve Bolt: T40 in 15mm round head 6.2mm thick, 69mm shank 9.2mm, threaded M8x1.25-11mm, 87.5mm OAL Sleeve: hard nylon 61.4mm L, 14.2mm (9/16") OD, 9.3mm (3/8") ID
swingstrkbolt.jpg | Hits: 929 | Posted on: 9/3/14 | View original size (3.55 MB)

Type 3 Bronco Swingaway Spare Carrier Strike Bolt & Sleeve

Bolt: T40 in 15mm round head 6.2mm thick, 69mm shank 9.2mm, threaded M8x1.25-11mm, 87.5mm OAL

Sleeve: hard nylon 61.4mm L, 14.2mm (9/16") OD, 9.3mm (3/8") ID
