grilleopening_9293.jpg '92-93 Grille Opening
IF THE IMAGE IS TOO SMALL, click it.

Similar to '94-97, which adds a rubber air flap to each side of the core support near 8B455.

Opening reinforcement F6TZ8A284AC
Bracket F2TZ8B455A
Stone Shield Air Deflector -17A861-
Pushpin 389358S
Lower air deflector F2TZ8327B
Pushpin 388577S (NN165F)
Radiator lower isolator/mount is E5TZ8125A
