6672-drums.jpg '66-72 Brake Drums IF THE IMAGE IS TOO SMALL, click it. Drum Backing Plates Bendix 319130L or 317363L= 11" '66-'75, driver side Bendix 319130R or 317364R= 11" '66-'75, pass side Wagner FF55264= 10" '66-'75 small bearing, driver side Wagner FF55265= 10" '66-'75 small bearing, pass side Bendix 80174L= 10" big bearing, '74-'75 driver side Bendix 80175R= 10" big bearing, '74-'75 pass side Bendix 3203097L= 11" '76-'77 driver side Bendix 3203098R= 11" '76-'77 pass side See also: [url=https://www.supermotors.net/registry/28823/88214-2][img]https://www.supermotors.net/getfile/1150814/thumbnail/20190701_162733.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1151008][img]https://www.supermotors.net/getfile/1151008/thumbnail/6670-brakes.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1151011][img]https://www.supermotors.net/getfile/1151011/thumbnail/6672-brakemc.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1151012][img]https://www.supermotors.net/getfile/1151012/thumbnail/7172-brakepark.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1150993][img]https://www.supermotors.net/getfile/1150993/thumbnail/66-rearsusp.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1150994][img]https://www.supermotors.net/getfile/1150994/thumbnail/7072-9inchlok.jpg[/img][/url] . [url=https://www.supermotors.net/registry/media/1150995][img]https://www.supermotors.net/getfile/1150995/thumbnail/6672-9inchopen.jpg[/img][/url] [img]http://classicbroncos.com/forums/attachment.php?attachmentid=364158&d=1429843488[/img]
6672-drums.jpg | Hits: 894 | Posted on: 7/7/19 | View original size (1.23 MB)

'66-72 Brake Drums
IF THE IMAGE IS TOO SMALL, click it.

Drum Backing Plates
Bendix 319130L or 317363L= 11" '66-'75, driver side
Bendix 319130R or 317364R= 11" '66-'75, pass side
Wagner FF55264= 10" '66-'75 small bearing, driver side
Wagner FF55265= 10" '66-'75 small bearing, pass side
Bendix 80174L= 10" big bearing, '74-'75 driver side
Bendix 80175R= 10" big bearing, '74-'75 pass side
Bendix 3203097L= 11" '76-'77 driver side
Bendix 3203098R= 11" '76-'77 pass side

See also:
. . . . . .
