9inch.jpg Ford 9" Exploded Ford 8.8" & 9" axles use 10 lug studs D6AZ-1107-A ('66-00) Dana 44IFS uses 10 lug studs D6TZ-1107-A ('83-96) Ford TIB axle uses 10 lug studs F4UZ-1107-A ('94-96) See also: [url=http://www.fordf150.net/forums/viewtopic.php?p=507588#507588]What's the DIFF?[/url]
9inch.jpg | Hits: 9826 | Posted on: 7/14/03 | View original size (129.55 KB)

Ford 9" Exploded

Ford 8.8" & 9" axles use 10 lug studs D6AZ-1107-A ('66-00)
Dana 44IFS uses 10 lug studs D6TZ-1107-A ('83-96)
Ford TIB axle uses 10 lug studs F4UZ-1107-A ('94-96)

See also:
What's the DIFF?
