'95-96 Bronco Front Disk Brake with floating calipers, 4WABS, 2-piece inner wheel seal, 3-screw auto hub locks; F150s do not have 4WABS, but are otherwise similar.
'80-93 Front Rotor
MotorCraft BRR8'79-85 Front Pads
Motorcraft BR43B'86-93 Front Pads
Motorcraft BR41B'94-96 Front Pads
Motorcraft BR46'94-96 Front Rotor
Motorcraft BRR56'80-96 D44IFS Outer Wheel Bearing
Koyo SET45'80-96 D44IFS Inner Wheel Bearing
Timken SET36'95-96 Front Inner Wheel Seal
Timken 710430'80-96 Spindle Seal Set
Spicer 706527X1 - Steering Knuckle - 3130(RH) 3131(LH)
2 - Front Disc Brake Rotor Shield - 2K004
3 - Seal, Spindle Inner - 1175 or 3299
4 - Bearing, Spindle - 3123 install with writing facing outward (inboard)
5 - Spindle - 3105
6 - Nut - 35704 tighten to 47 N-m (35 lb-ft)
7 - Seal, Rolling Diaphragm, Spindle Outer - 3254
8 - Seal, Inner Wheel - 1190
9 - Bearing, Inner Wheel - 4221 or 1201
10 - Race, Inner Wheel Bearing - 4222
11 - Hub, 4WD - 1104 (part of 1102)
12 - Race, Outer Wheel Bearing - 4222
13 - Bearing, Outer Wheel - 4221 or 1216
14 - Adjusting Nut, Wheel Bearing (2.5-inch rounded hex) - 3B459 Back off 90 degrees (1/4 turn); tighten to 1.8 N-m (16 lb-in); to align notch, tighten.
15 - Retainer Key - 3B549
16 - Thrust Washer (steel) - 3B458
17 - Thrust Washer (plastic) - 3B458
18 - Thrust Washer (splined) - 3B458
19 - C-ring - 3B457
20 - Rotor, 4WD - 1125 (part of 1102)
21 - Bolt, Wheel Hub (Lug) - 1107
22 - Brake Caliper Assembly - 2B120(RH) 2B121(LH)
23 - Bolt, Caliper Slide Pin - N807683-S60 (M8-1.25 x 65) tighten to 30-36 N-m (22-27 Lb-Ft)
24 - Spring, Brake Shoe Hold-Down - 2068
25 - Drag Cam Assembly - (part of 1K105)
26 - Lock Body Assembly - (
F6TZ-1K105-AA)
27 - C-ring - (part of 1K104)
28 - Dust Cap - 1K104
29 - Screw, Dust Cap - (part of 1K104) tighten to 4-6 N-m (35-53 Lb-In)
30 - Sensor, 4WABS Front - 2L373 or 2C204 ('93-96 Bronco only)
Standard ALS18531 - Screw, 4WABS Sensor - tighten to 4.5-6.8 N-m (40-60 lb-in) ('93-96 Bronco only)
32 - Shield, 4WABS Sensor - RH 4432D, LH ('93-96 Bronco only)
33 - Screw,4WABS Sensor Shield (12-point 6mm head) - ('93-96 Bronco only)
34 - 55-Tooth Speed Sensor Ring (Indicator),4WABS Front - E7TZ2B409B/F37A-2C182-AC ('93-96 Bronco only)
See the NEXT pic...
